Warner E-Series 2 mm Connector Holders with Straight Body Cross Reference

Warner Series Warner Product# Type Connector Suction Glass OD (mm) A-M Systems Product # Drawing
ESP-M10N W4 64-0992 Pellet 2 mm Pin No 1.0 669440
ESP-M12N W4 64-0993 Pellet 2 mm Pin No 1.2 669441
ESP-M15N W4 64-0994 Pellet 2 mm Pin No 1.5 669443
ESP-M20N W4 64-1260 Pellet 2 mm Pin No 2.0 669448
ESP-M10P W4 64-0995 Pellet 2 mm Pin Yes 1.0 670440
ESP-M12P W4 64-0996 Pellet 2 mm Pin Yes 1.2 670441
ESP-M15P W4 64-0997 Pellet 2 mm Pin Yes 1.5 670443
ESP-M20P W4 64-0998 Pellet 2 mm Pin Yes 2.0 670448
ESP-F10N W4 64-0980 Pellet 2 mm Jack No 1.0 673440
ESP-F12N W4 64-0981 Pellet 2 mm Jack No 1.2 673441
ESP-F15N W4 64-0982 Pellet 2 mm Jack No 1.5 673443
ESP-F20N W4 64-0983 Pellet 2 mm Jack No 2.0 673448
ESP-F10P W4 64-0984 Pellet 2 mm Jack Yes 1.0 674440
ESP-F12P W4 64-0985 Pellet 2 mm Jack Yes 1.2 674441
ESP-F15P W4 64-0986 Pellet 2 mm Jack Yes 1.5 674443
ESP-F20P W4 64-0987 Pellet 2 mm Jack Yes 2.0 674448
ESW-M10N W4 64-1011 Wire 2 mm Pin No 1.0 671440
ESW-M12N W4 64-1012 Wire 2 mm Pin No 1.2 671441
ESW-M15N W4 64-1013 Wire 2 mm Pin No 1.5 671443
ESW-M20N W4 64-1014 Wire 2 mm Pin No 2.0 671448
ESW-M10P W4 64-1015 Wire 2 mm Pin Yes 1.0 672440
ESW-M12P W4 64-1016 Wire 2 mm Pin Yes 1.2 672441
ESW-M15P W4 64-1017 Wire 2 mm Pin Yes 1.5 672443
ESW-M20P W4 64-1018 Wire 2 mm Pin Yes 2.0 672448
ESW-F10N W4 64-0999 Wire 2 mm Jack No 1.0 675440
ESW-F12N W4 64-1000 Wire 2 mm Jack No 1.2 675441
ESW-F15N W4 64-1001 Wire 2 mm Jack No 1.5 675443
ESW-F20N W4 64-1002 Wire 2 mm Jack No 2.0 675448
ESW-F10P W4 64-1003 Wire 2 mm Jack Yes 1.0 676040
ESW-F12P W4 64-1004 Wire 2 mm Jack Yes 1.2 676041
ESW-F15P W4 64-1005 Wire 2 mm Jack Yes 1.5 676043
ESW-F20P W4 64-1006 Wire 2 mm Jack Yes 2.0 676048

Warner E-Series 2 mm Connector Holders with 45° Angle Cross Reference

Warner Series Warner Product# Type Connector Suction Glass OD (mm) A-M Systems Product # Drawing
E45P-M10N W4 64-0908 Pellet 2 mm Pin No 1.0 669640
E45P-M12N W4 64-0909 Pellet 2 mm Pin No 1.2 669641
E45P-M15N W4 64-0910 Pellet 2 mm Pin No 1.5 669643
E45P-M20N W4 64-0911 Pellet 2 mm Pin No 2.0 669648
E45P-M10P W4 64-0912 Pellet 2 mm Pin Yes 1.0 670640
E45P-M12P W4 64-0913 Pellet 2 mm Pin Yes 1.2 670641
E45P-M15P W4 64-0914 Pellet 2 mm Pin Yes 1.5 670643
E45P-M20P W4 64-0915 Pellet 2 mm Pin Yes 2.0 670648
E45P-F10N W4 64-0900 Pellet 2 mm Jack No 1.0 673640
E45P-F12N W4 64-0901 Pellet 2 mm Jack No 1.2 673641
E45P-F15N W4 64-0902 Pellet 2 mm Jack No 1.5 673643
E45P-F20N W4 64-0903 Pellet 2 mm Jack No 2.0 673648
E45P-F10P W4 64-0904 Pellet 2 mm Jack Yes 1.0 674640
E45P-F12P W4 64-0905 Pellet 2 mm Jack Yes 1.2 674641
E45P-F15P W4 64-0906 Pellet 2 mm Jack Yes 1.5 674643
E45P-F20P W4 64-0907 Pellet 2 mm Jack Yes 2.0 674648
E45W-M10N W4 64-0924 Wire 2 mm Pin No 1.0 671640
E45W-M12N W4 64-0925 Wire 2 mm Pin No 1.2 671641
E45W-M15N W4 64-0926 Wire 2 mm Pin No 1.5 671643
E45W-M20N W4 64-0927 Wire 2 mm Pin No 2.0 671648
E45W-M10P W4 64-0928 Wire 2 mm Pin Yes 1.0 672640
E45W-M12P W4 64-0929 Wire 2 mm Pin Yes 1.2 672641
E45W-M15P W4 64-0930 Wire 2 mm Pin Yes 1.5 672643
E45W-M20P W4 64-0931 Wire 2 mm Pin Yes 2.0 672648
E45W-F10N W4 64-0916 Wire 2 mm Jack No 1.0 675640
E45W-F12N W4 64-0917 Wire 2 mm Jack No 1.2 675641
E45W-F15N W4 64-0918 Wire 2 mm Jack No 1.5 675643
E45W-F20N W4 64-0919 Wire 2 mm Jack No 2.0 675648
E45W-F10P W4 64-0920 Wire 2 mm Jack Yes 1.0 676640
E45W-F12P W4 64-0921 Wire 2 mm Jack Yes 1.2 676641
E45W-F15P W4 64-0922 Wire 2 mm Jack Yes 1.5 676643
E45W-F20P W4 64-0923 Wire 2 mm Jack Yes 2.0 676648

Warner E-Series 2 mm Connector Holders with 90° Angle Cross Reference

Warner Series Warner Product# Type Connector Suction Glass OD (mm) A-M Systems Product # Drawing
ERP-M10N W4 64-0940 Pellet 2 mm Pin No 1.0 669740
ERP-M12N W4 64-0941 Pellet 2 mm Pin No 1.2 669741
ERP-M15N W4 64-0942 Pellet 2 mm Pin No 1.5 669743
ERP-M20N W4 64-0943 Pellet 2 mm Pin No 2.0 669748
ERP-M10P W4 64-0944 Pellet 2 mm Pin Yes 1.0 670740
ERP-M12P W4 64-0945 Pellet 2 mm Pin Yes 1.2 670741
ERP-M15P W4 64-0946 Pellet 2 mm Pin Yes 1.5 670743
ERP-M20P W4 64-0947 Pellet 2 mm Pin Yes 2.0 670748
ERP-F10N W4 64-0932 Pellet 2 mm Jack No 1.0 673740
ERP-F12N W4 64-0933 Pellet 2 mm Jack No 1.2 673741
ERP-F15N W4 64-0934 Pellet 2 mm Jack No 1.5 673743
ERP-F20N W4 64-0935 Pellet 2 mm Jack No 2.0 673748
ERP-F10P W4 64-0936 Pellet 2 mm Jack Yes 1.0 674740
ERP-F12P W4 64-0937 Pellet 2 mm Jack Yes 1.2 674741
ERP-F15P W4 64-0938 Pellet 2 mm Jack Yes 1.5 674743
ERP-F20P W4 64-0939 Pellet 2 mm Jack Yes 2.0 674748
ERW-M10N W4 64-0956 Wire 2 mm Pin No 1.0 671740
ERW-M12N W4 64-0957 Wire 2 mm Pin No 1.2 671741
ERW-M15N W4 64-0958 Wire 2 mm Pin No 1.5 671743
ERW-M20N W4 64-0959 Wire 2 mm Pin No 2.0 671748
ERW-M10P W4 64-0960 Wire 2 mm Pin Yes 1.0 672740
ERW-M12P W4 64-0961 Wire 2 mm Pin Yes 1.2 672741
ERW-M15P W4 64-0962 Wire 2 mm Pin Yes 1.5 672743
ERW-M20P W4 64-0963 Wire 2 mm Pin Yes 2.0 672748
ERW-F10N W4 64-0948 Wire 2 mm Jack No 1.0 675740
ERW-F12N W4 64-0949 Wire 2 mm Jack No 1.2 675741
ERW-F15N W4 64-0950 Wire 2 mm Jack No 1.5 675743
ERW-F20N W4 64-0951 Wire 2 mm Jack No 2.0 675748
ERW-F10P W4 64-0952 Wire 2 mm Jack Yes 1.0 676740
ERW-F12P W4 64-0953 Wire 2 mm Jack Yes 1.2 676741
ERW-F15P W4 64-0954 Wire 2 mm Jack Yes 1.5 676743
ERW-F20P W4 64-0955 Wire 2 mm Jack Yes 2.0 676748

Warner Q-Series Holders With 1 mm Pin Cross Reference

Warner Series Warner Product# Type Connector Suction Glass OD (mm) A-M Systems Product # Drawing
QSW-A10P W4 64-0821 Wire Straight Port 1.0 660040
QSW-A12P W4 64-0822 Wire Straight Port 1.2 660041
QSW-A15P W4 64-0823 Wire Straight Port 1.5 660043
QSW-A17P W4 64-0978 Wire Straight Port 1.7 660045
QSW-A20P W4 64-0824 Wire Straight Port 2.0 660048

Warner Q-Series Holders With 1 mm Pin, Axon Threaded Collar Cross Reference

Warner Series Warner Product# Type Connector Suction Glass OD (mm) A-M Systems Product # Drawing
QSW-T10P W4 64-0837 Wire Straight Port 1.0 663040
QSW-T12P W4 64-0838 Wire Straight Port 1.2 663041
QSW-T15P W4 64-0839 Wire Straight Port 1.5 663043
QSW-T17P W4 64-1097 Wire Straight Port 1.7 663045
QSW-T20P W4 64-0840 Wire Straight Port 2.0 663048
Q45W-T10P W4 64-1071 Wire 45° Port 1.0 663240
Q45W-T12P W4 64-1072 Wire 45° Port 1.2 663241
Q45W-T15P W4 64-1073 Wire 45° Port 1.5 663243
Q45W-T17P W4 64-0972 Wire 45° Port 1.7 663245
Q45W-T20P W4 64-1074 Wire 45° Port 2.0 663248
QRW-T10P W4 64-1091 Wire 90° Port 1.0 663340
QRW-T12P W4 64-1092 Wire 90° Port 1.2 663341
QRW-T15P W4 64-1093 Wire 90° Port 1.5 663343
QRW-T17P W4 64-0977 Wire 90° Port 1.7 663345
QRW-T20P W4 64-1094 Wire 90° Port 2.0 663348

Warner Q-Series Holders With BNC Connector Cross Reference

Warner Series Warner Product# Type Connector Suction Glass OD (mm) A-M Systems Product # Drawing
QSW-B10P W4 64-0825 Wire Straight Port 1.0 667040
QSW-B12P W4 64-0826 Wire Straight Port 1.2 667041
QSW-B15P W4 64-0827 Wire Straight Port 1.5 667043
QSW-B17P W4 64-0979 Wire Straight Port 1.7 667045
QSW-B20P W4 64-0828 Wire Straight Port 2.0 667048
Q45W-B10P W4 64-1059 Wire 45° Port 1.0 667240
Q45W-B12P W4 64-1060 Wire 45° Port 1.2 667241
Q45W-B15P W4 64-1061 Wire 45° Port 1.5 667243
Q45W-B17P W4 64-0969 Wire 45° Port 1.7 667245
Q45W-B20P W4 64-1062 Wire 45° Port 2.0 667248
QRW-B10P W4 64-1079 Wire 90° Port 1.0 667340
QRW-B12P W4 64-1080 Wire 90° Port 1.2 667341
QRW-B15P W4 64-1081 Wire 90° Port 1.5 667343
QRW-B17P W4 64-0974 Wire 90° Port 1.7 667345
QRW-B20P W4 64-1082 Wire 90° Port 2.0 667348
